CR Rubber Sheet
CR or Chloroprene rubber ( Neoprene Rubber ) It has excellent mechanical and abrasion properties, it’s famous on it good performance of fire resistance(Pure Neoprene can reach V0 Standard), CR Rubber sheet easy to cut into all type of gaskets for the chemical and oil industrial.
Applicatioin
Neoprene rubber sheet widely used as gasket sheet material.
Technical Data – Commercial Grade
| Item | Specific Gravity |
Hardness |
Tensile Strength |
Elongation at break |
Working Temp. |
|---|---|---|---|---|---|
| HK36516 | 1.6g/cm³ | 65±5 ShoreA | 3MPA | 180% | -20 ~ +70°C |
| HK36515 | 1.5g/cm³ | 65±5 ShoreA | 4MPA | 200% | -20 ~ +70°C |
| HK35515 | 1.5g/cm³ | 55±5 ShoreA | 4MPA | 200% | -20 ~ +70°C |
Technical Data – High Grade
| Item | Specific Gravity |
Hardness |
Tensile Strength |
Elongation at break |
Working Temp. |
|---|---|---|---|---|---|
| HK36516P | 1.6g/cm³ | 65±5 ShoreA | 5MPA | 250% | -20 ~ +70°C |
Specification
| Thickness | Width | Length | Color | Insertion | Surface |
|---|---|---|---|---|---|
| 1-50mm | 1/1.2/1.4m | 5-20m | Black, Red, Green, Etc. | 0Ply, 1Ply, 2Ply, 3Ply | Smooth/Fabric |
