EPDM Rubber Sheet
EPDM or Ethylene Propylene Diene Monomer, We highly recommended for out door uses as it extremely resistant to oxidation, U.V. Rays and Ozone. due to its highly saturated polymer chain. However, EPDM does not have good oil resistance like Nitrile Rubber, Is resistant to many chemicals and solvents and shows, good resistance to many corrosive chemicals.
Applicatioin
EPDM rubber have excellent performance to resistant the ozone and UV irradiation. Can be used in the roof of the waterproof system, or cover for equipment or cargo fear of sunshine
Technical Data – Commercial Grade
| Item | Specific Gravity |
Hardness |
Tensile Strength |
Elongation at break |
Working Temp. |
|---|---|---|---|---|---|
| HK46516 | 1.6g/cm³ | 65±5 ShoreA | 3MPA | 180% | -30 ~ +80°C |
| HK46515 | 1.5g/cm³ | 65±5 ShoreA | 4MPA | 200% | -30 ~ +80°C |
| HK45515 | 1.5g/cm³ | 55±5 ShoreA | 4MPA | 200% | -30 ~ +80°C |
Technical Data – High Grade
| Item | Specific Gravity |
Hardness |
Tensile Strength |
Elongation at break |
Working Temp. |
|---|---|---|---|---|---|
| HK46515P | 1.5g/cm³ | 65±5 ShoreA | 6MPA | 300% | -30 ~ +80°C |
Specification
| Thickness | Width | Length | Color | Insertion | Surface |
|---|---|---|---|---|---|
| 1-50mm | 1/1.2/1.4m | 5-20m | Black, Red, Green, Etc. | 0Ply, 1Ply, 2Ply, 3Ply | Smooth/Fabric |
